LG-SL33– Multi-Frequency Locator

Key Features LEAKGEAR® LG-SL33

• Multi-Frequency Precision – Works with 512 Hz, 640 Hz, and 33 kHz sondes — ideal for LG C1 Inspection Camera and other pipe cameras.

• Extended Range – Detects active sonde signals up to 33 ft in open areas.

• Adjustable Sensitivity – Fine-tune gain from 0 to 100 for exact signal pinpointing.

• Audio & Visual Feedback – View signal strength on-screen or listen via built-in speaker or headphones.

• LCD Backlight Control – Easy-to-read display for bright sun or dark conditions.

• Long Battery Life – Built-in 7.4 V / 2200 mAh lithium battery provides up to 10 hours of runtime.

• Weather-Resistant Design – Rated IP65 for outdoor use around pools and plumbing sites.


Technical Specifications

Parameter Specification Locate Frequencies 512 Hz / 640 Hz / 33 kHz Power Line Locate 50 / 60 Hz Radio Frequencies 250 Hz – 40 kHz Receive Distance 33 ft (10 m, open area) Sensitivity Range0 – 100 (Adjustable) Audio Output Speaker / Headphone Display Type LCD with Signal Strength Indicator (%) + Adjustable Backlight Dimensions 27.2 × 9.4 × 4.3 in (690 × 240 × 110 mm) Weight (Unit) 4.4 lb (2 kg) Ingress Protection IP65 (Rain / Splash Resistant) Power Supply Built-in 7.4 V 2200 mAh Li-ion Battery Operating Time≈ 10 hours per charge Package Dimensions 29.5 × 11.8 × 7.9 in (750 × 300 × 200 mm) Gross Weight 13.2 lb (6 kg) Shipping Weight≈ 19.8 lb (9 kg)

Applications

• Pool and spa plumbing leak localization

• Pipeline and conduit tracking

• Underground utility locating

• Works seamlessly with LeakGear LG-C1 Inspection Camera and other 512 / 640 / 33 kHz transmitters


In the Box

• 1 ×
  LEAKGEAR® LG-SL33

• 1 × Lithium Battery (Pre-installed)

• 1 × Charging Adapter

• 1 × Professional Carry Case

• 1 × User Manual
